Ecolift

Ecolift

Battery Free | Power Free | Oil Free

Working Dimensions

Maximum working height: 4.20 m

Maximum platform height: 2.20 m

Basket dimensions: 850mm(L) x 644mm(W)

Working footprint: 1.28 m x 700 mm

Safe working load: 150 kg (1 person + tools)

Maximum manual force: 200 N

Maximum gradient for operation: 0 degrees

Maximum wind force: Internal use only (0 mph)

Maximum wheel force: 234kg

Maximum castor point load: 234kg (2.29kN)

Sound pressure level: less than 70Dba

Closed Dimensions

Length: 1.28m

Width: 0.70 m

Height: 1.94m

Weight: 305kg

Safety Features

l Auto-braked on entering basket

l ‘Auto-Lok’ brake on elevation

l Dead man’s handle

l Fail-safe lifting mechanism

As part of the Eco range the Ecolift still harnesses the

same ECO friendly revolutionary ‘Patented Stored Power

System’ as the Pecolift but at 4.2m offers almost a metre

extra in working height.

With no batteries (to change and look after) and no

hydraulic oil, the Ecolift is truly an Eco friendly solution.
