Pecolift

Pecolift

Battery Free | Power Free | Oil Free

3.5 Meter Working Height

Key Features

l Intuitive to operate – turn handle to elevate
l Patented lift mechanism, no power required
l Lightweight, easy to maneuver
l Small footprint (985mm x 700mm)
l Unlimited lift cycles, can be used 24/7
l Robust design for years of trouble free service
l Minimal operational cost, virtually maintenance free

Safety Features
l Auto-braked on entering basket
l ‘Auto-Lok’ on elevation
l Dead man’s handle
l Fail-safe lifting mechanism

Working Dimensions
Maximum working height: 3.50m
Maximum platform height: 1.50m
Basket dimensions: 720mm(L) x 600mm(W)
Working footprint: 985mm x 700mm
Safe working load: 150kg (1 person + tools)
Maximum manual force: 200 N
Maximum gradient for operation: 0 degrees
Maximum wind force: Internal use only (0 mph)
Maximum wheel force: 125kg
Maximum castor point load: 125kg (1.23kN)
Sound pressure level: less than 70 Dba

Closed Dimensions

Length: 985 mm

Width: 700 mm

Height: 1.55 m

Weight: 180 kg
